Ok hello, I'm going to make a "quick" video just showing the parametric CNC model I've
been working on here in Fusion 360.
Which is based on the the wooden plate, or the birch ply plate CNC that I've been making,
which I've nicknamed CNC Mountain.
I've just more or less finished the individual plates and I've done this while learning how
to use Fusion 360.
My machine is based on an opensource series by Openbuilds, and takes inspiration from
other similar machines including Open Builds Korea Lead Screw CNC Machine, C-Beam Sphinx,
Ultibot CB3030, and the R7 CB CNC, and also the videos of Martin Barfoed.
I'll link to all those things in the description.
But I wanted to make my own variation to satisfy some of the requirements that I might have
with a CNC machine.
And to also add my own design implementations and engineer things into the machine that
I think might be useful.
The firs thing were openings on the plates which would a proximity sensor.
Now while working on this particular machine I've been very conscious to try and set up
some parameters, so I can make some alterations to the machine which can then allow me to
adapt some of the features.
So for example if I want to change the opening diameter of the proximity sensor, because
for whatever reason I've found a new sensor that works better, maybe it's cheaper and
I want to incorporate it into the design - I can track down onto this list of parameters,
and I can change an expression and then the opening will change its diameter.
So I think I called this proximity sensor.
If I change that, this should change as well.
And the hole just changed.
And the surrounding area which I've described as the mount.
If I want to change that to 15mm for whatever reason, for aesthetic reasons that changes
as well but the spacing of the holes and everything else stays more or less in the same.
And if I got to another part of the machine you can see a big chunky mounting plate with
the hole.
If I undo change parameter, and go back down - in fact I think I've changed both there.
I've also added some openings that I can access the grub screw at the back of some of the
plates which tensions or pulls the nutblock onto the ACME threaded rod, so it reduces
the play.
The other alterations did from my prototype CNC machine was to change from large vwheels
to mini ones, for example on the y-plates.
When I initially modelled the plates with two types of wheels I noticed they didn't
line up.
The larger wheel has a slightly different thickness, and it wasn't sitting entirely
aligned in the centre of the aluminium extrusion.
Even if I added or subtracted a shim on the various wheels this didn't seem to solve the
problem.
If I show you this side of the machine here, and I get rid of that plate.
You can see a similar thing.
So there wheels line up well there, but the next wheel is pushing into the extrusion.
I modelled this machine with metric spacers but the one I actually built used imperial.
So they were 6.35mm and I think that wheel touched onto the opposite side, but of course
I was using birch ply plates so they have been other factors involved in the spacing
problems.
What I've actually done in preparation of cutting of some test plates is buy a sheet
of 0.2mm PTFE and a hollow punch set with a centring point to make my own PTFE washers
to use to space out the wheels a little bit more accurately.
And place them in-between these two washers here until the wheels line up a little bit
better and all making contact they way they should be.
Designing the machine by parameters has meant that I can adapt thing very quickly.
I can go down and change the spindle plate thickness which are these things here, although
I'm going to leave them at 15mm.
It's a practical size.
I've got the stepper hole spacing which are the holes which the longer spaces go between
the plate and the stepper motor - and then bolt the motor in place and then the hole
for the leadscrew is centred between those four.
So depending on the size of the stepper motor I could in theory increase the size of the
stepper motors and quickly adapt the plate dimensions.
I've got the spindle diameter so if I happen to get a smaller spindle - like a 60mm one.
Just put 60 and it becomes smaller, but I think I that might be a mistake there.
So that's something I've got to work on.
So I've adapted that but these ones here haven't updated because I haven't set the dimension.
If I go to this, right click and edit profile sketch it should be able to do this.
So D, click, and this will be spindle diameter.
Lets see what happens when I do this?
Bugger.
I need to lock these - fix.
Centre to that.
That to there.
Raa what's going on there.
It's 80 - ahh and then we want to divide that by 2.
The radius.
Ok that looks correct and I can stop sketch.
You can see I've ever so slightly extended that curvature into the opening so it actually
clamps down.
Obviously I haven't tested it out yet so it might need to be a bit more, or less.
If I got to modify, change parameters, and spindle diameter, and I change it back to
60mm because I want to use a smaller spindle.
Boom it changes.
Obviously it's not in the best position for that size of spindle.
I probably have to relate that to overall shape.
Don't know if it's something I can actually do.
Right click, edit profile sketch, I can delete that.
D that to that.
That's a bit of an odd one.
22.3mm.
Essentially this is how I've been doing it, I write some parameters, I include them into
the body or the component (sketch) that I am designing, and I make a change and see
what happens.
Yeah so that's doing what it should be doing.
So now I can adjust the opening of this particular part and it can accommodate different types
of spindles.
I've also made sure that I line up the openings with the plates so this is the z axis here.
The only thing I haven't quite worked out how to do is to line up the centre of a hole
on one plate to a edge of a profile, of another plate.
So if i change, going back to parameters again.
And I look for plate thickness and say we're making this really thin - like 3mm coz we're
using stainless steel plates.
123, go computer.
Don't break.
Spinning wheel of doom.
You can see the plates but the hole hasn't adjusted for that.
I can't quite figure out how to do that.
I also got the bearings holes, so I can again adjust the type of bearing - the depth that
it goes into the plate and also the opening here for the leadscrew.
So if I decided I want to try and make a slightly more robust machine I can get a thicker leadscrew,
and then adapt the bearing holes on all the plates.
Yeah essentially that's it.
I haven't done any detail on this machine.
I've not added screws or brackets or anything that I didn't have too.
You can see I've got wheels on this side (at the top) because I needed to identify the
spacing but ones I got those right I didn't bother adding wheels on the other side.
This is purely just to illustrate the design principles and make sure things actually line
up and actually do what I want them to do.
And it's all joined more or less correctly as far as I can tell.
So I can grab on different plates, and move things around as if it was actually a real
CNC machine.
Ok I just realised something else.
This corner here, if I was cutting out with a 6mm cutting bit, I would have a curve edge
which would effect how the part of the machine joined together.
What I could do is start a new sketch on this plate, and cut a circle into the inside edge,
or create a fillet on the outside edge of the adjoining piece, adding a 3mm radius curve.
I had to change some of the constraints on the sketches to get this to work, and select
new points to join the pieces within the model, but in the end the spindle bracket looks like
this now.
So you can see the shapes follow the same kinda curvature, on either side.
And I've tried too add a radius (fillet) onto the design wherever you have an inside corner
because that what's going to be left behind when it's cut out using a router cutter.
So the plates should look like how they would come out.
The other thing I forgot to mention is I can actually change the dimensions of the CNC
machine itself.
So if I want to make it wider, I can put the width down that I want and the machine redesigns
and then obviously I can take the measurements off the machine to get a rough idea of how
big certain parts would be.
When I was building the original machine, I did have some problems with the machine
screws because they do come in specific sizes and with some of the parts, for example the
y plates and the mini v wheels which go into the c-beam.
If the machine screws are too long they will scratch onto the aluminium.
So it's not as simple as it looks but you know, there's a lot of information in this
model that I can extract before going into a new build.
And I think the nice thing about this sort of design and this approach to modelling an
idea out, is that this is essentially a blueprint which isn't stuck down on paper.
So I think what I'm going to do now is export these plates and make them available first
to my patreons who have been supporting me since I've started this CNC channel, and I'll
leave it with them for a few weeks so they get a head start with building the CNC mountain
- as I'm calling it.
And after that time I will make these files available on the openbuilds platform which
is where I've been sharing some of the videos of the build process.
This is an opensource machine so please don't write down in the comment - you should patent
that.
This isn't how it works.
This is about working collectively and I wouldn't have been able to do half the amount that
I have done if it wasn't for the information available on OpenBuilds, and on YouTube, and
the generous people who share their creativity and time.
So thanks again to them, thanks again to my patreons for supporting me, and for any of
you random stragglers who've turned up and managed to watch this.
I actually fell asleep while editing this video because I found my own voice so boring.
For more infomation >> ¡Marc Anthony está feliz y enojado al mismo tiempo! | Un Nuevo Día | Telemundo - Duration: 2:33.
For more infomation >> ¡El padre de Cristian Castro está enfermo y sin dinero! | Un Nuevo Día | Telemundo - Duration: 0:58.
For more infomation >> ¡Evita que la playa y la piscina arruinen tu cabello! | Un Nuevo Día | Telemundo - Duration: 3:53.
For more infomation >> THE FLOOR IS LAVA CHALLENGE MÁS EXTREMO DEL MUNDO - EL PISO ES LAVA FAILS - Duration: 6:08.
For more infomation >> "Mariposa de Barrio", la serie que enamoró a los latinos | Un Nuevo Día | Telemundo - Duration: 2:39.
For more infomation >> ¡Julián Gil no está pagando la manutención de su hijo! | Un Nuevo Día | Telemundo - Duration: 1:18.
For more infomation >> ¿Hicieron trampa "Los Trump" para ganar las elecciones? | Un Nuevo Día | Telemundo - Duration: 3:37.
For more infomation >> ¡Marc Anthony está cansado que hablen de Juan Gabriel! | Un Nuevo Día | Telemundo - Duration: 2:46.
For more infomation >> Recetas de cocina: Cómo hacer unas Chuletas Can Can | Un Nuevo Día | Telemundo - Duration: 5:52.
For more infomation >> El horóscopo de hoy, 12 de julio de 2017, por el astrólogo Mario Vannucci | Un Nuevo Día | Telemundo - Duration: 3:43.
For more infomation >> ¡Disfruta de las locas aventuras de Camilo en Rusia! | Un Nuevo Día | Telemundo - Duration: 4:52.
For more infomation >> SYKA - PIO PIO (VIDEOCLIP) - Duration: 3:50.
For more infomation >> ¡Protege a tus mascotas de la peligrosa influenza canina! | Un Nuevo Día | Telemundo - Duration: 4:53.
For more infomation >> AMD Ryzen 1700 - Review - Duration: 10:40.
For more infomation >> ¡Revisamos el closet a Ivy Queen, la reina del reggaetón! | Un Nuevo Día | Telemundo - Duration: 6:34.
For more infomation >> Los robots sexuales: una industria en crecimiento | Un Nuevo Día | Telemundo - Duration: 1:16.
For more infomation >> ¿Cómo evitar que tus hijos sufran una insolación? | Un Nuevo Día | Telemundo - Duration: 6:09.
For more infomation >> ¡Rodney Ingram, el mexicano que conquista Broadway! | Un Nuevo Día | Telemundo - Duration: 3:48.
For more infomation >> Supervivientes 2017: Kiko se corta en el pulgar de su mano derecha abriendo un coco - Duration: 2:30.
For more infomation >> Charlie Chaplin Pintor Apaixonado - Duration: 12:28.
For more infomation >> Free Spin 8 Ball Pool 2017 - Get Extra Spin Link - Duration: 1:03.
For more infomation >> Peugeot 508 SW Allure 1.6 BlueHDi 120 PK EAT6 STOELVERWARMING - Duration: 1:01.
For more infomation >> What I bought from the Outlets! | Au pair Everyday #22 - Duration: 3:13.
For more infomation >> Juving i Røafallene - Duration: 1:44.
For more infomation >> Trump Jr on Promised Clinton Dirt I love It MSNBC - Duration: 6:18.
For more infomation >> WHO AM I - quem sou eu (PILOT) - Duration: 0:53.
For more infomation >> Hyundai ix20 1.6i i-Motion | Automaat | Climate | - Duration: 0:45.
For more infomation >> Toyota Verso-S 1.3 VVT-I ASPIRATION Airco Camera Bluetooth - Duration: 1:00.
For more infomation >> Toyota Prius 1.5 VVT-i Business Edition - Duration: 1:02.
For more infomation >> Honda Civic 1.4i City - Duration: 0:53.
For more infomation >> Mazda Premacy 1.8I EXCLUSIVE NETTE AUTO - Duration: 1:00.
For more infomation >> Toyota Yaris 1.3 VVT-i Cool 5-deurs | Airco | Radio CD-speler | NIEUWE APK | - Duration: 0:54.
For more infomation >> Toyota Urban Cruiser 1.3 VVT-i Dynamic Navi, Ecc, Keyless entry, Lmv - Duration: 0:57.
For more infomation >> Toyota Verso-S 1.3 VVT-i Aspiration Special | Airco | Parkeercamera | Trekhaak - Duration: 1:00.
For more infomation >> TJ Aparecida | Coisas do Brasil: conheça o bar de gelo em Campos do Jordão/SP - 12 de julho de 2017 - Duration: 4:19.
For more infomation >> LIGUEI PARA O MC KEVINHO😍 - Duration: 2:41.
For more infomation >> Reservoir Flog #1 Cyflwyniad - Duration: 1:55.
For more infomation >> Paul-Walker-Hymne: "See You Again" knackt YouTube-Rekord! - Duration: 2:01.
For more infomation >> Bepantol® Baby e Instituto Guga Kuerten - Duration: 0:32.
For more infomation >> Os efeitos do sobrepeso e da obesidade na saúde (legendado/traduzido) - Duration: 2:03.
For more infomation >> ¿Cómo se puede denunciar el material obsceno que ronda por las redes sociales? - Duration: 2:15.
For more infomation >> TJ Aparecida | Previsão do tempo - 12 de julho de 2017 - Duration: 1:17.
For more infomation >> ||Kilka propozycji zestawów|| SSO|| - Duration: 0:48.
No comments:
Post a Comment
