Let's do another trip to the United Exploitation country. We already visited the casino and
the photo manager, so let's continue this road and head to the animals.
This is a 200 points exploitation challenge and it doesn't provide us anything to reverse
engineer. So we must be able to blindly exploit this.
The description reads:
After decades of research, we finally managed to catalogue all the animals on the planet
earth. Including very rare pictures!
Often times the text can contain hints, but this one is so short and generic, that it
probably doesn't really include anything.
So let's load the challenge onto the board, and get started.
Let's quickly checkout the functionality. We see here a menu and a prompt where we can
enter characters, The menu items indicate that we can enter a c to print a cat or a
d to print a dog or a m to print a mouse. We can also try to enter some more characters.
Like write "cat", and while it still just prints what the first character says, it's
interesting that we can enter more characters and get the whole string.
So we could definitely try and see what happens when we enter more characters and you might
already notice some odd behaviour, but let's not get ahead of ourselves, this was the mistake
I first made when approaching this challenge. Let's do this systematically.
I decided to use a whiteboard to visualize what goes on in my head as well as to document
each discovery. Especially with blind challenges like this you need to build a good mental
model of the program running there. And taking notes is crucial.
So I start with writing down what I know. That there are three different characters
in the menu. M, C and D, so I wonder, is there maybe a hidden menu option?
Let's find out. Let's write some code that tries out every character and we look at the
response. By now you already know this code, this just
sets up the serial connection with the board and some helper functions.
So first we read until we get the menu enter promot so we can send a character, and it
makes sense to put this into a loop. So now we print the last output, construct our payload,
which is just one character and enter it into the menu. Then we read the result, and try
the next character. When we try to run it it doesn't find serial,
I forgot to enter the virtual environment. If you do any python programming make sure
to checkout virtualenv. So now it works and it tries every character. But it's a a lot
of output, I think it's better if we remove all the newlines and also show the raw bytes
with repr(). Now it's easier to spot stuff. When you now look through here, we notice
that some characters, for example the percentage sign are turned into a null-byte. There are
a couple of them. No idea if it's important in some way or not, but let's make sure
to note these down. It's important to not ignore an oddity like this.
But besides that we didn't find any secret menu option. So let's think of something
else we could try. How about trying out different lengths of input. Let's modify our code
to test that. So instead of using the loop number as a character, we use it to change
the length of the input. And we just try it with some As.
When we run it we can observer multiple things. First of all, the input seems to be capped
at like 59 or 60 characters. Our input keeps growing, but the output stops. So let's
take notes of that. The first shorter lengths happened obviously
very quickly so if we look there again more closely, we notice that with the 11th character
we screw with something and suddenly leak a lot of bytes.
Let's write it down. So that's very interesting, what is so special
at this last character position. We can write some code to explore that further. Let's
enter a couple of Cs and then play with this exact value.
And here is a very interesting result. You see we always enter a bunch of Cs but it only
prints the amount of bytes we specify. So nullbyte will print nothing and 3 will print
3 characters. And so when we get to high byte values, like actual ascii characters, we obviously
leak like 30 or mroe bytes. It doesn't leak up to 255 bytes, so there is a limit, but
we can write this down. And we can change from 11 chars dumps some memory, to that the
11th char controls the output lenght. So now we now that we have this big range
of memory we can write to to, and certain positions can contain important information.
So for example the 11th character is the print length. And to take notes we can enter the
bytes that we leak into this long array. Also the ascii character number 7, hex 37,
prints the maximum amount of output. After that the output doesn't grow, that's why
I write a 7 here. So no we wonder, what could other positions
in this memory here mean. When we fuzzed the input length we used the
character A, so I'm wondering, what if you used a character that actually prints a picture,
like c. The cat. So modify the code slightly and then let's see what happens. And very
quickly the cat disappeared. And if you do the same thing for dog, the
dog picture disappears a little bit later. So you can write down how many characters
it takes to reach a point where a particular picture is not shown anymore. That's very
interesting. What could we possibly overwrite in that memory that causes this behaviour?
Look at the memory we leaked and mark the apparently interesting offsets. It's clear
that these bytes must mean something. these bytes have something to do with cat. So let's
modify the code. So I add the three bytes I know are the correct value, but replace
the first one to try different bytes. But it doesn't do anything. It seems like
there is only one correct value that leads to printing the cat. In retrospect it's
probably like a stack cookie. We must use that one particular value.
So let's move on to the next byte. Do the same thing. And this time it does print the
cat more often. But it's a bit weird. I have strong feeling that it is part of an
address, but I don't know. Let's move on to the third byte. Oh holy
crap! This shifts the rat. This clearly moving the cat around. So that is definitely part
of the address, or offset into memory where the cat is stored.
Also it's very interestign to see some weird characters before and afterwards. It's not
just 0 and cleary not just random garbage. So that's something we shouldn't ignore.
But we still didn't get the big breakthrough. But if you look at the leaked memory dump,
you will notice that the dog and mouse seem to have 4 interesting bytes, while the cat
only ahs three. Maybe the 4th byte of the cat just happens to be 0, but actually it
also has 4 byte. Ignore some of the notes here, I was just exploring some random ideas.
Anyway, let's try the 4th byte. wooooh. This output is damn interesting. This
is gold. If you look very closely, you notice that
these weird characters have indeed a pattern. Doesn't this look like the dog? The shape
is there, just the wrong characters. And here this looks like the mouse.
This reaaaaly stinks like XOR. The pattern is there, just the characters have to be transformed
into something else. Si let's write a simple python script that
tries out all different XOR keys, applies them to the leaked character output and prints
it. And when we now look through the possible outputs, we find a cleartext mouse!
So to recap, We have a big chunk of memory. And at certain offsets we know there is some
kind of information regarding the animal pictures. At least the last two bytes affect what we
read from memory. We were able to extract an XORed picture from the mouse by changing
the bytes of waht corresponded to the cat. So we clearly control here the location of
memory we read. But the output is XORed.
So now, we have a first serious shot at getting the flag.
Let's modify our loop to iterate over all 2 byte values. Then we take the leaked memory
output, pass it to a function that brute forces all possible XOR keys. And our assumption
is, that some memroy location will contain the flag, just XORed, so if we find the word
FLAG in any of the decrypted memory leaks, we won.
Makes sense, right? So let's try that! Oh man, I did first make
here a mistake. I meant to brute force the 3rd and 4th byte, but if you look closely
I brute force the 2nd and third. Obviously that didn't work. So after fixing that and
some other minor mistakes I let it run, and it pretty much immediately outputs the flag.
Let's hand it in and collect our 200 points.
