Hey y'all.
Welcome to Part 1 of my series on v-carving for the absolute beginner.
Before I get started, let me say that I am in no way sponsored nor endorsed...
...by Vectric Ltd., nor any router bit company or manufacturer that I may mention.
I'm doing this series to help the person who has never done this before...
...learn the v-carving process...
...understand a little bit about the router bits involved...
...and create and finish a v-carve project within the CAD/CAM software.
I'm going to be talking about VCarve Pro...
...during this presentation because that's the software I use.
But everything I'm going to show you in this series...
...applies equally to VCarve Desktop, VCarve Pro, and Aspire.
So with that out of the way, let me start by saying to...
...some of the more experienced users, and some of the seasoned veterans out there...
...that some of this that you're going to see will be old news.
You already know a lot of this.
Again, I'm doing this for the absolute beginner.
So I'll ask you to please remember that none of us were born knowing this information.
We all had to learn it somewhere.
So if you'll please keep that in mind, I'd appreciate it.
To the absolute beginner:
I'm here to help you try to...
...understand a little bit of how this process works.
To help you with bit selection and help you get started in v-carving.
If you have any questions or comments, feel free to leave them in the comment section...
...or contact me through my website...
...and I'll get into that a little bit more later on.
So, taking the advice of Lewis Carroll...
...we can go ahead and begin at the beginning...
...and use this to illustrate something that I see come up a lot.
And that is the difference in the various router bits.
Here we have a 90 degree v-bit...
...and here we have a 60 degree v-bit.
The main thing to remember about these bits is...
...that the higher the number, the more shallow the angle.
This bit, as measured from this corner here to the tip ...
...and then this tip to this corner here...
...that angle is 90 degrees.
On the other side, over here...
As measured from this corner here, to the tip...
...and then from the tip down to this corner here is 60 degrees.
The rule of thumb to remember is; the larger the number, the more shallow the angle...
...the smaller the number, the steeper the angle.
When we talk about cutting diameter, what we mean is...
...the diameter from this corner here...
...to this corner here on the V bit.
These carbide cutters here will cut this V shape from here to here.
Same thing with the 60-degree.
From this corner here, to this corner here...
...that is the widest these bits will cut.
That'll become important a little bit later on
Probably the first place to start is...
...why would we want to use v-carving in the first place?
Well, that answer can be summed up in two words - square corners.
As you can see, in this photograph of a simulation in VCarve Pro...
...if we were to pocket out a square with just a standard 1/4 inch end mill, for example...
The bit has a radius.
It is a round bit, and when it gets over here in these corners, it's going to cut that radius.
It's going to machine the radius of the bit, whatever that may be.
Using a v-bit, however, it will not only machine out the entire area...
...but it'll also add this chamfered detail...
...and take advantage of the z-axis to create these sharp corners.
Up here, what would happen is, depending upon your toolpathing strategy...
...the bit would plunge down into the center...
...if you're using the offset strategy...
...and start hollowing out this area here...
...until it got to the profile pass...
...in which case it would come around and clean up...
...leaving these rounded corners.
If you were using the raster strategy, it would...
...move back and forth to hollow out this pocket...
...then do a final profile pass to clean it up.
With the v-carve toolpath...
...what it will do is use a large area clearance tool to machine out...
...the bulk of the material here, the same as this one...
Then you would do a tool change, to your v-bit...
...and it'll do the profile pass here.
When it gets to one of these corners, the X and Y will start moving outward...
...while the Z raises...
...which will give us this nice square corner here, and this faceted appearance.
So that's how the machine reacts to a v-carve toolpath.
One of the more common questions I get is related to the depth of cut in a v-carve toolpath.
Let's take a look at this in the context of v-carving text.
I have an illustration here to show you what I'm talking about.
This is a representation of a 90 degree v-bit ...
...and a 60 degree V bit.
These here and here are the same.
One of the determining factors of how deep of v-bit will cut is...
...the width of the space between the vectors you're attempting to cut out.
If we have, for example...
...this simple text right here - a capital I and a capital O...
The v-bit in a v-carve toolpath is going to carve away all the material inside these vectors.
It's not going to cut on the vector...
...it's going to cut inside the vectors.
It's going to carve away all the material here until...
...the edges of that v-bit are riding along this vector here...
...and this vector here.
It's this space between this vector and this vector...
...as well as...
...the angle of the bit that's going to determine that cutting depth.
In this example here, if a 90 degree v-bit...
...and a 60 degree v-bit...
...are attempting to cut to the same 1/2 inch width...
...the 60 degree v-bit is going to cut approximately twice as deep...
...as that 90 degree v-bit.
So it's the width in between the two vectors that you're trying to machine out...
...as well as the angle of the bit...
...that's going to determine how deep that bit cuts.
Now, there are ways you can control the depth of cut...
...but we'll get it into that in a later video.
When it comes to bit selection...
...just know that the steeper the angle of the bit...
...the deeper it's going to cut...
...to get the same width as a bit of a shallower angle.
To demonstrate that, I'll take this capital I and this capital O...
...and I'll calculate a couple of toolpaths for them to show you the difference.
Another thing to pay attention to...
I said the distance between this vector here and this vector here...
..that also means the distance between them over here.
And the distance between this vector here and this vector here.
V-carving is considered, by some, to be 2 1/2 dimensional (2.5D) carving...
...and by others to be 3 dimensional (3D) carving...
...meaning that all three axes work at the same time...
...to carve out this area here.
Let me go ahead and calculate the toolpath and I'll show you exactly what I mean.
I'll select the text here...
...we'll go over to the Toolpath tab...
I'm going to go down here to the V-Carve/Engraving toolpath.
Select that.
We're going to set our start depth to 0.0
We are going to start at the top surface of the material.
When v-carving, always set your Z zero to the top of the material.
So I'm going to use a start depth of 0.0
I'm not going to use a flat depth. We'll get into that in another video.
The v-bit I'm going to use for this demonstration is a 90 degree v-bit with a 1/2 inch cutting diameter.
I'm not going to make any changes here at all...
I'm simply going to call this...
...v-carve... 90 degree...
...then we'll calculate....
...and we have our toolpaths created, and if you notice...
...it looks a little bit different than what we would imagine.
If we get over here into the O, we see it's going to have to make a couple of passes at different depths.
I'm going to leave the material alone...
I will select the toolpath color; black.
...and we'll preview this toolpath.
As you can see, when we get in here and zoom in a little bit...
...our tool carved a straight line down here at a depth...
...then when it got to this corner...
...it made a curved pass...
...and the Z kicked in, and retracted that bit...
...to make this nice narrow portion in here.
Then it came back...
...lifted up here to make that square corner, then lifted up here to make that square corner.
By the same token, you get over here and look at this O...
Because we have a wider area here between this outside and the inside of that letter O...
...we cut pretty deep here...
...then as this vector narrowed down, the Z kicked in, lifted that bit up...
...and we cut much shallower here.
Now if you recall from the other tutorials that we did...
...if we look down here at my XY and Z display here...
...you'll see my Z is at 0.0 because it's on the material's surface.
But when I come over here and drop that pointer down into...
...this trench, for lack of a better term...
...we can see that it cut almost 1/4 inch into the material.
We're at -.2467
Almost 1/4 inch into the material.
That was so the edges of this bit could get in and ride the edges of those vectors.
If we go over here to the letter I we can see...
...it's about the same...
...maybe a little bit less; -.2069
That's how deep it had to plunge to get these real wide areas.
If you watch the letter O here, as those vectors get closer and closer together...
...the depth on my Z gets shallower and shallower and shallower...
...until we get up here to the top...
...and we've cut just a little over 1/16 inch deep.
My point in all of this is that it's a combination of the width of the space between the vectors...
...and the angle of the v-bit, that dictate how deep that bit is going to cut...
...in order to to do the v-carving that we want it to do.
Let me reset my preview...
I'll close that...
...and we'll go back into the 2D view.
The vectors are still selected.
I'll do another v-carve and engraving toolpath...
But this time I'll switch over to...
...a 60-degree v-bit with a 1/2 inch cutting diameter.
I'll make no other changes here except to call this...
...60 degree...
...calculate...
...and already we can see a little bit of a difference.
To carve the letter I, it's going to have to do it in a couple of passes.
To carve the letter O, it's going to have to make two or three passes...
So, let's go ahead and preview this toolpath. We'll set my toolpath color to black...
...and we'll preview that toolpath.
Again, we got a good result...
...but when we zoom in...
...keeping an eye down here on our Z readout...
...we can see that in order to carve this letter O...
...it had to cut .420"...
.4250" almost .430"... deep to carve this letter O.
So you see what I mean...
If our material is a 1/2 inch thick, we have machined almost...
...well, actually we've machined a little over 2/3 of the way through that material to get this width...
...out of a 60-degree V bit.
We come over here to the letter I...
We're a lot better off...
...we're at .356"
We're over 1/4 inch deep, but we're not quite...
...3/8 inch deep.
For a situation like this...
I think we would be better served running...
...the 90 degree v-bit...
...rather than the 60 degree, simply because we can still get our width...
...without carving as deeply into the material.
This is something that will come with experience - knowing when to use which bit.
And this is the time to experiment.
Now we know that this is going to cut...
...about two-thirds of the way through the material...
...that's probably not our best way to go.
I'll reset the preview, and I'm going to delete that toolpath.
If I were going to carve this...
I would use the 90 degree v-bit.
Then I know I'm only going to carve about 1/4 inch deep...
...maybe a little more, maybe a little less.
Text size, or the size of the object that you are carving out...
...will help dictate which bit you should use.
If I select these vectors and go back into my text editor...
...we can see I just have the I and the O here...
My text height is 3 inches tall.
If I were going to carve anything 4.5 inches or taller...
I might want to switch over to a 120 degree v-bit...
...so it carves even shallower than this.
If I were going to make this text height 1/4 inch tall...
I might want to switch to a 30 degree v-bit...
...so that it carves deeper...
...and we don't lose any detail if we sand after cutting.
That's a lot of information to take in on the first outing.
The takeaways I hope you get from this are...
...it's the bit angle...
...and the width of the area that you're attempting to cut...
...that determine the depth of that cut.
The lower the number on the angle of your bit...
...the steeper the angle is.
The higher the number, the shallower it is.
I think we're called this the end...
...of the introductory video to this series.
In the next video, we'll get into...
...v-carving a simple text sign.
Then in future videos we'll get into carving to a flat depth...
...and maybe doing some pictures.
But we'll end this one here.
If you'd like to continue to follow this series...
...or if you'd like to follow along with some of my other CNC adventures...
...I do hope you'll subscribe to my channel.
If you have any questions, comments, or concerns at all...
...feel free to leave me a comment down in the comment section.
If you'd rather not leave a public comment...
...head on over here to my website
marklindsaycnc.com
...and click on this Contact Us link right here.
You can send me any comment you'd like...
...and I will receive it via email.
I do read every comment I receive...
...and try to answer every single one of them.
While you're over here...
...take a look in the shop...
...and you'll find I have a few DXF file downloads here...
...that are absolutely free.
And of course, you can check out my coffee cups and t-shirts if you're of a mind to...
...but there are some free CNC file downloads here in DXF format.
marklindsaycnc.com is sponsored by Harneal Media.
The web design company that specializes in website design and hosting for makers and the maker community.
Harneal Media, as well as I, are both proud members of the Makers Media Network.
So that'll wrap up this first episode.
Again I'd like to thank you very much for watching.
If you got anything at all out of this video, please give me a thumbs up down below.
And if you'd like to follow along in my CNC adventures, please hit that subscribe button...
...and hit that Bell button right next to it.
That way you'll get a notification whenever I post a new video.
Whether you subscribe to me or not, I'd like to thank you very much for taking the time to watch this video...
...and y'all take care.
For more infomation >> 【仮想通貨都市伝説】ビットコイン創始者サトシ・ナカモトのBTC保有量判明!?全て売られたら大暴落!?取引所ビットメックス調査!仮想通貨市場天才の捜査開始!?未来人AI?最新情報!最前線暗号通貨ニュース - Duration: 3:52.
For more infomation >> Carrioner ogląda "Niesamowite Rzeczy" *ostra reakcja* (ARCHIWUM) - Duration: 3:58.
For more infomation >> CORSICA LINEA - Méditerranée | Marseille departure for Tunis - Duration: 3:45.
For more infomation >> Sandy e Junior retomam parceria, se emocionam e internet vai ao delírio; assista - Duration: 2:32.
For more infomation >> Yanna Lavigne exibe o corpaço na praia com Bruno Gissoni e a sogra, veja! - Duration: 1:50.
For more infomation >> Ex-BBB Emilly Araújo exibe cinturinha e é acusada de usar Photoshop - Duration: 1:39.
For more infomation >> Citroën DS3 1.6 e-HDi So Chic - Duration: 1:11.
For more infomation >> Citroën DS3 1.6 e-HDi So Chic - Duration: 1:11.
For more infomation >> Vivian Amorim é substituída no Vídeo Show, choca fãs e repercute na web - Duration: 4:28.
For more infomation >> MON VOYAGE BELGIQUE PAYS-BAS LA SUITE - Duration: 11:25.
For more infomation >> Stephen King - L'ombra dello scorpione versione integrale - 1990 (sub ita) - Duration: 8:33.
For more infomation >> 3D恥力全開 台南行#2 一秒cos? ft.乖該和他的朋友們 / 音軌Vlog - Duration: 3:05.
For more infomation >> Bruna Marquezine dá resposta atravessada em seguidor após sofrer acusação - Duration: 5:24.
For more infomation >> Bolsonaro se desboca em comício e insinua que William Bonner levou chifre; confira o vídeo - Duration: 6:20.
For more infomation >> Artesplorazioni: arte programmata - Duration: 4:04.
For more infomation >> Discreta, Simaria posta raro clique de seu marido bonitão e surpreende internautas - Duration: 5:18.
For more infomation >> Edinburgh Vlog Day 1: Camera obscura and Harry Potter - Duration: 19:40.
For more infomation >> Origami Maple Leaf - Duration: 3:13.
For more infomation >> Volvo XC60 2.0 T5 | R-Design | Leer | Navigatie | Xenon | Harman/Kardon | LED - Duration: 1:09.
For more infomation >> Evangelio de hoy, Domingo 2 de Septiembre del 2018 - Duration: 3:59.
For more infomation >> Breast Cancer Blood Test
For more infomation >> Alfa Romeo Spider 2.0-16V T.Spark EEN HEEL LEUKE CABRIO - Duration: 1:06.
For more infomation >> Medical related degrees that aren't medicine. Stepping Further #31 - Duration: 4:12.
For more infomation >> РОНАЛДУ РАСКРЫЛ КТО ОН ЕСТЬ НА САМОМ ДЕЛЕ! НОВЫЕ ПОДРОБНОСТИ! - Duration: 3:33.
For more infomation >> ЕДИНОРОЖКИ Куклы ЛОЛ Сюрприз LOL POP Surprise Распаковка лол Цветочек ВИДЕО ДЛЯ ДЕВОЧЕК - Duration: 10:33.
For more infomation >> Remèdes Super Express! Apprenez Les Meilleurs Traitements Naturels Pour Supprimer Les Cernes Et Les. - Duration: 4:35.
For more infomation >> 重磅！99式坦克首次出国参加战略大演习，为何不派99A主战坦克？ - Duration: 4:04.
For more infomation >> 千億劉強東遭傳涉性侵被捕 奶茶妹被酸 - Duration: 1:59.
For more infomation >> Telltale|TWDG| He won't bite! (humor/meme) - Duration: 6:00.
No comments:
Post a Comment
