Hello, Piston Kirk is back!
Today we will see how to replace the brake pads
on a Boxster 986.
The first step is to lift the car with a jack to remove the wheel.
The jack's point of support is here.
Position it underneath, then lift the car.
The rear wheels can be locked by the parking brake.
It is therefore very easy to loosen the bolts when it is in the air
On the other hand, the front wheels are not blocked
therefore, the wheel turns when one try to loosen the bolts.
To avoid this problem,
before lifting the car with the jack,
you have to loosen the bolts very slightly,
take a full turn to unlock the bolt
The antitheft nut is located in the front trunk,
at the spare wheel, in the tool bag.
Now that we have the antitheft nut,
we will be able to slightly loosen the five bolts
then we lift the car with a jack
until the wheel does not touch the ground anymore.
unscrew the 5 bolts completely
Then remove the wheel.
Do not forget to put the wheel under the car to secure
in case the jack piston gives way.
Now that the view is clear,
we will be able to inspect the state of the brake pads.
Normally, brake pads must be checked every 15,000 kilometers.
It must be at least 2.5 mm thick.
It is necessary to measure the thickness between these two points.
If you go below that 2,5 mm limit,
the disc will start to wear the warning contact wire of the brake pad's wear indicator
and you will then see a warning light that will appear on your dashboard.
So, not only you will have to replace the contactor for a price of 9 euros each,
but in addition you willl have to use a diagnostic computer to turn off the light
and if you do not have one, you will have to go to your Porsche dealer.
Before replacing the brake pads,
we will also measure the state of wear of the disc.
For that, we have to measure the gap here.
On a 2.5L Boxster and a 2.7L, the disc thickness must be at a minimum
22 mm in front and 18 mm behind.
For 3.2L it must have minimum 26 mm in front and 22 mm behind.
As the disc is still good,
we can limit ourselves to the replacement of brake pads.
To remove the pads,
we will start by removing this clip with a pliers.
Now that the holding rod is no longer held by the clip,
we will be able to remove it by gently tapping on
using a hammer and a screwdriver.
Once the rod is removed,
it will be necessary to remove the cable of the wear indicator which interferes with the extraction of the spring.
Remove the end of the cable from the wear indicator
pressing each side with a small flat screwdriver,
then, remove the cable from the spring.
Once it's done,
nothing holds the spring back, you can remove it.
As the new pads can measure up to 9 mm more than the ones we will remove,
we will have to make room to insert them.
So, before removing the old pads,
We will first push them to stick them as much as possible against the walls of the brake caliper,
thus, we will free up space for the news pads
Normally professionals use a special tool to spread the brake pads,
but to limit costs, I'm going to use a simple pliers,
taking care to put fabric on the brake caliper to protect the paint.
Of course, the pliers is less convenient than the specific tool,
because not only must I proceed in two stages, first pressing the first brake pad then the second
but also because you have to show some strength.
The other problem,
it is that when you tighten the second brake pad, the first tends to return to its place.
It is therefore necessary to maintain with the hand the first brake pad
while squeezing the second.
Now each brake pad has been repelled, can be removed.
Once the brake pad is out,
it is easier to unclip the head of the wear indicator.
If the head is damaged or broken,
we will have to replace the whole cable.
To remove the old cable,
we will have to go to the plug that is here.
Before, you have to unclip the cable that is tied in two places.
The first clip that is near the pads
then remove the cable from the second clip that is behind.
We can now unplug,
starting by unclipping the metal latch.
As it is no longer locked, just pull the plug
then replace the new cable.
Do not forget to lock again
and put back the two clips located behind.
Before installing new pads,
we'll have a look on it.
Depending on the model, the pack of four pads will cost you between 90 and 110 euros
In theory on a 2.5L and a 2.7L
the pads are supposed to be 11 mm thick in front and behind
while on a 3.2L
it is 12 mm thick in front and 10.5 mm behind.
Yet on my new pads,
I have 1 mm less in front and 0.5 mm behind.
This less thickness is not harmless,
this represents a reduced service life of 10.5% up front
and 6.25% at the back.
That said, do not see evil everywhere,
it does not necessarily come from a desire of the manufacturer to harm his client,
this may possibly come from a manufacturing tolerance
or a desire to facilitate the passage of pads during replacement.
But I do not exclude that it is perhaps a way like any other to increase profits.
Let's close this parenthesis on the thickness of platelets.
Before installing new pads, make sure you have the right ones.
So we will compare the old with the news.
As can be seen, everything is in order, they are identical.
before putting them in the caliper it will be necessary to prepare them.
Some spray anti-squeak grease
on the surface that is in contact with the pistons
to limit noise and wear.
Others use tube grease
that they spread on the surface with the finger.
Count about 12 euros for the spray
and 17 euros for the tube.
Be careful, do not use any grease.
Special brake greases must be used
able to withstand high temperatures above 1000 ° C (1832 ° F)
For example, the grease I used can withstand up to 1400 ° C (2552 ° F)
This also prevents the parts from welding together in case of overheating.
Be very careful to put this grease on the metal surface and not on the friction surface.
Otherwise, you will have a hard time stopping your car.
We will also put a little grease on the lateral support points of the pads
Be careful not to overflow the friction zone.
Now we can slide the pads in their place,
one after the other.
Then we put back the spring.
Then pass the cable into the notch of the brake caliper
first wear indicator head in the first brake pad.
Clip the cable in the spring,
then insert the second wear indicator head into the second brake pad.
Now replace the support rod.
Be careful to put the hole up so you can insert the locking clip.
Push the rod to the stop,
then replace the locking clip.
It's not quite finished yet,
before changing the pads of another wheel,
you have to put pressure on the pistons of the brake caliper first
to push the brake pads against the disc.
Enter in the car
and press the brake pedal several times
until you get resistance.
this operation must be done between each pads change
because if you push back the pads of the 4 wheels at the same time
without returning the pistons to their original position each time,
the brake fluid of the pistons will go up in the tank
which may overflow it.
Since we have access to the brake disc,
we will take the opportunity to remove the dust that has accumulated in the holes
which will improve the cooling.
This cleanup operation is only necessary for 3.2L
because if you have a 2.5L or a 2.7L
your brake discs are not perforated
Now you can put back the wheel by tightening the bolts crosswise.
Once a bolt is put, it is necessary to put the next one in a diametrically opposite way.
For example, we put the first here,
the following there,
the third here,
the fourth there
and the last here.
Start by screwing the first turns by hand
to be sure of not distorting the thread.
Theoretically you do not have to force.
Then screw it gently until it forces.
Once the five bolts are tightened without forcing too much,
use a torque wrench,
set the tightening torque to 130 N · m
then squeeze the first until you hear a clicking sound that tells you it's good.
Then tighten the one that is diametrically opposite
and so on until the bolts are tight.
If you are on the rear wheels, the wheels are blocked by the parking brake,
so you can squeeze when the car is still on the jack.
If you are on the front wheels,
after having lightly tightened, it will be necessary to lower the jack a little bit
for the tire to come into contact with the ground with enough pressure
to block the rotation of the wheel.
Then tighten the 5 bolts to 130 N · m
then lower the jack and remove it.
Here, the first wheel is finished, it remains only to reproduce the same operation again three times.
Before you start, you need to know some things:
it may seem obvious to many of you who are used to repair cars
but I know from experience that part of my audience is composed of neophytes,
it is therefore good to recall some basic elements.
The first is that never replace the pads of a single wheel,
otherwise braking will not be uniform.
The pads must be replaced in pairs of wheels:
the two front, the two behind or the pads of four brake caliper at the same time.
The second point to know,
it is that your brake pads will reach their best coefficient of friction
after about 250 km (150 miles).
During this period of time it is better to avoid making emergency braking
as far as possible.
It's going to be time to take a ride on the road.
But before, we'll check that the pedal brake responds correctly.
Once you have pumped with your foot up to have resistance,
turn on the engine.
Normally, the brake assist must engage
and the brake pedal must go a little deeper.
Now we can take a ride to make sure the car brakes properly.
Before concluding I would like to touch on one last point:
Keep in mind that it is not just the brake pads or disc to be replaced.
the brake fluid is also damaged with time,
it can absorb moisture and becomes less efficient.
In theory, it should be replaced every two years.
If you do not have the "Traction Control" option or the "PSM" option
The replacement of the brake fluid is an operation that you can do yourself.
Attention, the brakes must be purged in a certain order:
rear right
then left back
and then right front
then left front.
if you do not follow this order
you may have problems with the ABS of the car.
If you have the "Traction Control" option or the "PSM" option
that is to say one of these two switches on the dashboard,
Warning !
To bleed the brake system,
it is imperative to use a Porsche diagnostic software
to start the purge procedure and open the valves.
It is better not to do this operation yourself.
It is better to entrust this work to your dealer
to avoid ending up with a bad braking.
Now you know how to change your brake pads
for a price ranging from 112 to 130 euros.
But keep in mind that even though the procedure is simple
she does not tolerate the slightest forgetfulness,
because unlike the previous tutorials I made,
this time, it's your safety that depends on it.
So be very meticulous and get started!
See you next time!
For more infomation >> Mortal Kombat 11 - Trailer Oficial de Sonya Blade - Ronda Rousey - LEGENDADO PT-BR - Duration: 2:52.
For more infomation >> నీ Goalsని Achieve చెయ్యటానికి కావల్సిన 5 సూత్రాలు | Kavitha Ajay | Josh Talks Telugu - Duration: 14:02.
For more infomation >> Говорящая Том Бег за Сладостями Супер Крутой Агент Анджела! Новое обновление Talking Tom Candy Run - Duration: 6:00.
For more infomation >> Comment fidéliser ses clients à vie ou pour la vie - Duration: 9:23.
For more infomation >> Чехия. Злата Прага, воспоминания (часть 1) - Duration: 2:10.
For more infomation >> 日産スカイラインGT-Rは未だ現役！ - Duration: 4:30.
For more infomation >> Аниме Приколы под музыку #78 | Смешные Моменты Из Аниме | Anime COUBS - Duration: 8:11.
For more infomation >> [Chương 33] ✔ Truyện ✔ [ Love by chance the series ] ✔ Được Gọi Là ✔ Tình cờ yêu - Duration: 47:01.
For more infomation >> Grupo Científico LifEscozul®
For more infomation >> 25-year anniversary of Northridge quake comes with warnings I ABC7 - Duration: 2:11.
For more infomation >> California's effort to end cash bail on hold - Duration: 1:40.
For more infomation >> LAUSD bargaining talks ongoing as Day 5 of teachers strike remains I ABC7 - Duration: 2:36.
For more infomation >> Как иммигрировать в Канаду по провинциальной программе? - Duration: 3:37.
No comments:
Post a Comment
