- We get a lot of concerns on the channel
about buying second-hand e-bikes.
At the same time, we get a lot of concerns
about the longevity of e-bike motors.
Well, today we're gonna put all those worries at bay.
I'm gonna have a look at a very inexpensive way
how to refresh your Bosch Performance Line CX motor.
Steve, before we begin, let's talk about the Bosch warranty
on the Performance Line CX.
After all, you are a service agent for--
- I'm a Bosch service center agent.
- All right.
So what happens if you have got one of these motors
and you've had it for less than two years?
- So if you bought a new bike,
you cover the bike for two years.
So if your motor goes wrong,
it's a complete new motor. - Wow.
- Nothing gets opened up. - That's pretty cool.
- The motor's have been out since 2015
so there's a lot out there, they get a lot of wear,
they're used hard, and it's like a bottom bracket,
anything is gonna wear.
- So what happens if you do happen to get a new unit
under your warranty, does your warranty get extended
for a further two years?
- So yeah, yeah you get an additional two years.
It's just-- - That's pretty cool.
- Which is a cool thing, a very good thing.
- Yeah, so if you've got any problems in your motor
in that two years, then you can just simply get
back to Bosch and they'll renew it for you, right?
- That's correct.
- If your motor is within the warranty,
can you fiddle with it and take it apart?
- You can't touch it.
(laughing)
That voids the warranty. - Right.
- These little screws here have got
rubber coating all over them.
If that rubber coating isn't on there anymore,
that means you've been inside it
and you have no warranty.
So don't go taking it apart
if you're within your warranty period.
Just go back to your Bosch dealer.
- Alright, now my eyes been drawn to this
little box over here.
What have we got over here?
- [Steve] Okay, so this is a service repair kit
for motors that are no longer in warranty.
- Right.
- So it's a motor, it's got bearings
like your bottom bracket.
- It's gonna have wear and tear, right.
- It's gonna have wear and tear.
If you start to feel your motor bearings
getting rough and noisy, noisy's the main thing.
You start to hear a bit of noise.
This is the kit you need, it's a service repair kit.
It changes the main drive bearing.
- Right, great, well I think without any further ado, Steve,
let's get stuck in and fix this new kit, to this old motor.
- So, Steve, the first thing we do
is we keep everything clean.
And one another thing is -- - Yes, I've got that
on the checklist.
- Ya got that?
- I'm gonna be doing the checklist on this motor.
If ya don't mind. - Yeah, it's really important
that when we open this unit up,
everything is really clean.
You see that we've got stainless steel worktops.
- Well, it is like a kitchen as you've rightly called it.
- So, first thing is, we got to get clean,
so I'm gonna put my gloves on, don the gloves.
I bring my cleaning bucket into play.
And, I'm gonna put the motor in the cleaning bucket
and I'm gonna take my spray cleaner.
This is one of the new range
for Muc-Off, which is specific e-bike range, which is good.
It's actually a dry cleaner, so you haven't
got to get it wet, so you haven't got to worry about that.
- I guess you can get cleaner from any other brands,
like WD-40 and everything like that.
- Yeah, there's lots of cleaners.
So we give that a wipe over, make sure
everything is super clean when we come to break into it.
- There she is! - Onto the bench.
- I'll clean up after ya. - Get my bucket away.
You can tick me off there for cleaning the motor.
- We've done that.
- We've done the cleaning of the motor.
First job is, we remove the circlip.
So, circlip pliers.
- That's not a bad pair, is it?
Good solid pair of circlip pliers.
- Yeah, they're handy.
- I can tick that off then, Steve?
- Yeah, tick that off then, thank you.
The next thing we do is - Open her up?
- Remember I said about all the rubber in the seals.
- Yeah. - We gotta get that out.
It's a right pain, so we have to get our little pick
in there and get it out. - Right.
- And luckily, what we did earlier.
- Yeah, this is actually a procedure, isn't it?
- Yeah, it is a procedure, yeah it is.
We've got a checklist and everything.
So, the first thing we do is we loosen the box off.
And it's all just, we've got six T25 bolts here,
that we need to remove.
- Those are the ones you cannot touch, if your motor
is still under warranty.
- You certainly can't.
So, we got this going and to speed it up, I'm gonna
get my power drill - Is that a Bosch power drill?
- It is a Bosch power drill, yeah.
Yeah, look at that.
- Fit a lock ring.
- Fit a lock ring? - We've got a lock ring.
The lock ring is fitted.
So, bearing puller.
- Bearing puller goes over the top like hangs on the lock
ring and then we wind it on the crank bolts.
Can you see it lifting there? - Yeah.
- Look at that.
- I can now check that off I think.
- I think you can.
We've lifted it.
And we lift the motor and
we're all out. - I mean, she's not too
bad inside really.
- Well, it's gonna to be spotless inside
they're so well sealed.
So we got seals all around the edge, the edge of here.
- Yeah. - You can see inside.
The first thing we do is we check to make sure
everything is clean.
Everything is good and that shows there's no contamination.
- No signs of corrosion or anything like that?
- No, look at it.
It's like. - Yeah.
- It's like new. - Yeah.
It's just making a noise it's all.
- Yeah, it's making a noise and as you can see, you've
got no more crank axle in here.
And it runs on a bearing.
- I'm I gonna check off,
check for signs of damage or corrosion?
I think we're good aren't we?
- We've checked and we're done, yeah.
- Ah, right.
- Okay, so now we remove the freewheel sprocket.
And this is this unit here.
And that just press fits and that comes out.
It's really important that we don't touch
the shaft, we only touch this, because
we're gonna reuse that.
So, for the time being I'm gonna put that
on the bench, there.
- But is it worth opening up?
I'm quite eager to see what's in the box.
Is it a good time now or should we wait?
- I think we should.
(laughing)
I think we should, let's do it.
- Let's go see what's in this Bosch box there.
Ah, so there you go, that's it.
There it is Josh.
- [Steve In Black] It's like Christmas, isn't it?
- [Steve] It is like Christmas.
We gotta keep this really clean, so
- [Steve In Black] Okay.
- Make sure you don't...
- Sorry, I just wanna show you guys
there, what we've got here.
It seems to be lots of parts in there.
- [Steve In Black] Whole kits, o rings, and
- [Steve] Special grease.
- [Steve In Black] Special grease.
Ah, all the replaceable bolts.
Ah, that's pretty good, isn't it?
- [Steve] It's the whole lot, yeah.
- [Steve In Black] Well leave that there.
What's else we gotta do
before we get the new part in, then?
- So we need to remove the locating pin.
It's a pin that the sprocket (mumbles).
- Yeah, I can see the locator pin there.
- Okay, and that's it.
- There's one of them.
- Yeah, so pliers. - Yeah.
- [Steve] We're just gonna lift it out.
Give it a bit of a twittle.
There she is. - [Steve In Black] Yeah.
- [Steve] Out.
- [Steve In Black] And the rubber seal as well?
- [Steve] There's a little rubber seal.
Sits on the little rubber seal.
- Is there another o ring in here?
- Now the other o ring, is the o ring that
sits on the shaft, here. - [Steve In Black] Yeah.
- [Steve] So again with the pick, we're gonna
pull this out, and get rid of that o ring.
- [Steve In Black] Next, I step, I think we're done.
So we've got the lubricating pin.
Check.
- Done that.
Check PCV heat pad is on PCV?
- Ah, now, this is the heat pad here.
- [Steve] This little thing here.
And we're on.
So, we're covered.
We're ready to go.
- So we're done on the first part of the process
of opening the motor?
- Yeah, we've done it.
- Now we're onto stage three. - Okay, now the next thing.
Before we put the new one on.
We need to give this a quick clean.
So, first of all we need to make sure there's no
dirt around the edge.
So, I'm gonna take my one and three cloth,
lint-free cloth that was.
Spray some cleaner on that.
And just work around the edge, being careful to
brush outwards and not inwards, because anything
there, we need to push outside the motor.
- [Steve] Okay, so we've got the rubber washer.
- [Steve In Black] Yeah.
That sits on the rubber sleeve.
- [Steve In Black] Yeah. - [Steve] Yeah. That goes on.
And then peel this adhesive backing off.
They've done a good job, they've made it really simple.
And then you locate this into there, and push it into place.
- [Steve In Black] Boom!
- [Steve] Done.
- (Steve in Black] Boom!
Are you gonna put that pin,
while you're at it?
- [Steve] The pin, drops in, and slides on.
And we're done.
So, now we need to clean the bottom bracket shaft.
So, just to make sure everything is nice and clean.
Before we put the o ring on.
- Steve, can I put the o ring on?
- You can, Steve.
But before you do that, you need to grease on the shaft.
- You can do that. - Shall I do that?
- Okay, I'll do that.
So we just get my little brush and
we'll just paste it around
here, make sure it's all in the right place.
- [Steve In Black] Good to go right?
- [Steve] Good to go.
- [Steve In Black] Stick it on there.
Gently lift.
I can't get it, it's just too much of a fiddle.
You do it.
- [Steve] So we'll get that down and we'll move it
down to the right recess, which is that one there.
- [Steve In Black] Boom!
- [Steve] And then we're in place.
- [Steve In Black] Right, I just need to
update my tick offs.
Clean rubber housing.
Clean the BB shaft.
O ring, (mumbles) done that.
I feel like that moment has come when we can
open the package up.
All we've got is six bolts left, yeah?
- Yeah, they're the retaining bolts for the motor.
We need those for (mumbles).
- Can, I open the packet?
- Yeah, let's open it, yeah.
- [Steve In Black] There ya go, that's them
I'm interested to see what you get for your money here.
Wow, that's a pretty significant part.
- Be careful not to touch the inside of it, we need
to keep it - I'm gonna put that there.
So you be careful when you take this out.
So I guess,
I guess that comes out
and there it is.
And that is your new unit.
I mean you get quite a bit for your money, there
don't you really.
So, we're talking.
For this kit.
How much is it for the kit?
- Well, the kit is, 99 pounds, for the kit.
That's good isn't?
It's gonna totally refresh your bike, right?
- Yeah, you think about what a bottom bracket
costs, in a bike.
- Yeah, exactly.
- It's like, it's good value.
(mumbles)
- [Steve] Look at the amazing detail of the bearings?
That's a really complicated bearing.
- [Steve In Black] So, can I just give this to you?
I feel like that uh.
- [Steve] Yeah, let's take it.
Yeah, let me take it.
- Next job.
- Next job.
We're gonna grease this sprocket, ready to go on.
So, sprocket, grease.
- [Steve In Black] Bosch grease?
- [Steve] Bosch grease.
Work it around.
- [Steve] Quite nice doing that.
It feels like icing a cake.
Get the brush and just wipe it all into it's place.
- [Steve In Black] Honestly, this motor is gonna be
so smooth when we put it back together.
- We've greased this.
And we pop it into place.
- [Steve] So that sits, the locating pin,
that we stuck on with a pad. - [Steve In Black] Yeah.
- [Steve] This sits in there and presses into that
little wheel there.
So, it's just a case of dropping it in.
And that is located.
That is done.
- Guess all is required now is, to pop the freewheel,
uh thingamajig on? - Yes, remember this is
is the bit that we don't touch.
So, we need to give this a clean.
Let's give it a clean.
Where's my cloth, lint-free cloth?
- [Steve In Black] Here ya go.
- What did you call it?
- Lint-free cloth.
There's no lint in this cloth.
And so for the first thing is we're gonna clean
this, but we're not gonna touch the shaft, we're just
gonna get the old grease.
It's actually still amazingly clean.
But we give it a wipe off because we have the new grease.
So we put new grease on.
So, there we are.
New grease.
Again, work it around.
Paint brush there.
It's like being like a dental nurse.
Paint brush?
- Oh sorry, there ya go.
- We're fully greased up.
- Yeah, greased up.
Slot her in.
Slot her in there or slot her on there?
- [Steve] It's gonna go onto the shaft here.
So we're gonna drop it in.
- [Steve In Black] Engaged?
- [Steve] Make sure it's engaged.
Fit it in with a coax.
Can you see that?
The wheels are in motion.
Look at that.
We located.
- Well, can I go back to my checklist?
- Yep.
- I neglected it for a minute.
Greased all that.
Greased that.
Greased sprocket.
Checked the new cover seal and see if it's not damaged.
- Check to see if cover seal is not damaged.
- Okay, did you do that?
I've done that.
- [Steve In Black] Check and see if cover
seal is all in place.
- [Steve] Cover seal all in place?
- Yeah.
And I think, now too, uh, put the top on the pie?
- We're ready to go with just the icing.
So, we take this, we check the seal is good.
We gonna flip it over, and not gonna touch
any of this.
Gonna flip it over, and drop it, into place.
I say drop it gently, ease it into place.
So, there we are Steve.
We've dropped it into place.
We've done it.
Okay, so next thing, Steve.
Circlip back on.
This is important, so circlip,
open it up a little bit,
drop it into place.
And there we are we located it.
And that's it, done.
- All that I'm seeing now Steve, is six bolts.
- Six, bolts.
- Yeah, we're gonna put the bolts in.
And I'm now gonna remove my gloves, because
I've got grease on them.
- Means I can help you with this, then?
- You can do that.
- [Steve In Black] I can see you eagerly waiting there
with the Bosch screwdriver.
- [Steve] I am, now this is important.
When you do this, you need to make
sure that the pressure is right.
- [Steve In Black] Exactly.
- It's like doing the car wheel.
Let's alternate sides first?
- Exactly.
- Don't go in the clockwise or anticlockwise motion.
There ya go.
- So, I got my drill, and I'm just gonna loosely drive
these down.
- [Steve] Like the car wheel nuts.
Do opposite sides.
- [Steve In Black] Boom!
- [Steve] So, there now at least you're done.
So, what we now need to do is get the
six newton meters.
We need to get our torque wrench.
We'll just give them, and do it like the car wheel.
Do opposite sides.
- Alright, Steve, we only got a couple of
things left to tick off there.
- We're nearly ticked off, aren't we?
- Fit it back in the bike and
it says here, diagnostic.
- Diagnostic is great.
We plug it into the laptop and it'll check on
the whole motor.
Make sure everything is working as it should.
But, it's also an opportunity
to the upgrade the latest firmware.
Two years ago, 2016.
Bosch upgraded to the...
- The eMTB,
- MTB right.
eMTB mode.
- It used to be called Sports and then eMTB mode.
And that's the mode that will work between, flows between
- It's like (mumbles) my car.
- Right, it works to how much power you're putting down.
It gives you that, you pedal harder, you get more power.
So, you're not gonna (mumbles)
- Make sure you get that eMTB upgrade on your bike.
- You're not gonna hit turbo when your not expecting.
- Okay, one more thing I was gonna ask you.
Now that's fitted.
What's the warranty situation with that bike now?
With that motor?
- So what we've done there, the new drive bearing
has now got a two year warranty on it.
Which is great, because you're covered.
If it goes wrong within two years.
It's warrantied.
- So yeah, that's great.
Depends on where you live and the
conditions you live in, and the ground
conditions, every motor, in different part of the whole,
is gonna have a different wear age, right?
- That's a really important thing.
- Yeah.
- Where you're using it.
What you're getting it.
How muddy you're getting it.
How you clean it as well.
Don't go into it with a jet wash.
- Yeah.
- Try and keep it as - But I think the important
part is like you said, Steve, is like be proactive,
you know, keep an eye on your motor,
and give your motor some love.
And give it a bath.
Steve, thanks so much for showing us around the fix
on this motor and - Thank you.
- And don't forget to check out the Bicycle Kitchen.
- [Steve] My web address is bikekitch.com
- Bike kitch? - Bike kitch.
We leave the link at the bottom of this video.
- [Steve] There's a whole section of on what we
do with this thing.
Which you'll find out on the site.
- [Steve In Black] So let, one final thing.
Money-wise, we're looking at 99 pounds for the part.
- (mumbles)
- So, we're looking at a couple
hundred quids to get this done?
See there ya go, I hope to see your comments below.
I hope it's taking away some of your worries and fears,
not only, about buying second-hand e-bikes,
but of the longevity of the e-bike motors in general.
Don't forget to like, share, and subscribe to the EMBN.
You'll see some more Bosch content as in one on gearing,
which you'll find.
For more infomation >> 【PCシージ】しーじる てけとーに配信 - Duration: 1:11:27.
For more infomation >> Ford Fusion 1.6 16V 74KW 5DRS FUTURA PLUS AIRCO LMV - Duration: 1:14.
For more infomation >> Peugeot 108 1.0 e-VTi 5DRS. AIRCO/LED - Duration: 1:21.
For more infomation >> Ford Fiesta 1.5 TDCi Titanium 5drs NAVI/AIRCO/LMV/ - Duration: 1:09.
For more infomation >> Crenças Limitantes: Desperte seu Potencial! Ate onde suas crenças podem te levar | Marina Carvalho - Duration: 12:01.
For more infomation >> BBB 2019: "Namoro" de Isabella e Maycon termina antes de começar - Duration: 10:24.
For more infomation >> Come Superare La Paura Di Parlare In Pubblico (E Non Solo) Con Lisa Nichols - Duration: 5:53.
For more infomation >> Giật mình với khoản tiền thưởng thống kê nhanh cho ĐTVN sau khi đánh bại Jordan vào Tứ kết Asian cup - Duration: 21:22.
For more infomation >> Peugeot 108 1.0 e-VTi Active - Duration: 1:07.
For more infomation >> Isola dei Famosi 2019/ Anticipazioni e cast, Filippo Nardi: "mancano solo 4 giorni, vado a lavorare" - Duration: 4:06.
For more infomation >> Peugeot 108 1.0 e-VTi Active ::: #YesWeKHAN ::: - Meeneemprijzen - Duration: 1:11.
For more infomation >> Fabrizio Corona: «Sono tutto rifatto. Con Belen tornerei subito, io e Asia Argento due anime folli» - Duration: 16:33.
For more infomation >> Napoli 2-1 Lazio | Ancelotti Post-Match Press Conference | Serie A - Duration: 2:36.
For more infomation >> (合作) 底妝不用換季！3個小技巧讓底妝在冬天又貼又持久 ft. 蘭蔻零粉感超持久粉底 - Duration: 6:28.
For more infomation >> Citroën DS4 1.6 e-HDI Chic AUTOMAAT dealer auto! parkeersensoren! nette conditie! - Duration: 1:13.
For more infomation >> История США: как ГЕОГРАФИЯ СДЕЛАЛА США сверхдержавой? - Duration: 9:13.
For more infomation >> Kingdom Hearts : สรุปจักรวาล #7 (Kingdom Hearts 1) - Duration: 10:59.
For more infomation >> Introducing Robert Weaver, Director of Property, Property Partner - Duration: 3:59.
For more infomation >> Nejlepší kamarádka Vondráčkové: OBROVSKÝ VZTEK Lucčina multimilionáře! - Duration: 4:13.
For more infomation >> Nissan QASHQAI 1.2 DIG-T 115PK - Duration: 1:14.
For more infomation >> Alfa Romeo Giulia 2.0T 200PK Super Automaat (climate control - cruise control - navi - halfleder bek - Duration: 1:13.
For more infomation >> Alfa Romeo Giulia 2.0T 200PK Super Automaat (climate control - cruise control - navi - halfleder bek - Duration: 1:09.
For more infomation >> 【韓国旅行】最新版！弘大(ホンデ)の洋服レポ！冬物セールも始まってさらに激安に！爆買いするならセール品を狙えの巻【ファッション】 - Duration: 12:28.
For more infomation >> The Dodge Ram SRT-10 Is Still The Coolest Truck Ever Built - Duration: 2:00.
No comments:
Post a Comment
